Gearless machine MARGADRIVE MD 320-400

1,100.001,190.00

Clear

Description

MARGA DRIVE MD 320-400

ID:0074-0263

Permanent Magnet Synchronous Gearless Traction Machine

Specifications
Voltage 380v
Roping 2:01
Wrap single
Elv.Load 320-630kg
Elv.Speed 0.5-2.5 m/s
Sheave Diam 320mm/400mm
Duty S5-40%ED
Starts Per Hour 240st/H
Max.Static Load 2000KG
Weight 300KG
Brake DC110V 2*1.3A
IP code IP41
Ins.Class F



Additional information

Weight N/A
Dimensions N/A
Roping System

2:1, 1:1

MGL load (KG)

320 (4 persons), 450 (6 persons), 630 (8 persons)

Shave diameter (mm)

320mm, 400mm

MGL Speed (m/s)

0.5, 1.0, 1.6, 1.75, 2
